Carrier 340793-762 Replacement Part
Note: Some models may require the pressure switch to be changed as well with this replacement inducer. Please call us at (734) 326-3900
Includes:
- (1) - Draft Inducer Motor Assembly Kit (340793-762)
Specifications
- Motor Manufacturer: Fasco
- Motor Model #: 71500178
- Fasco Motor Type: 50FA
- Voltage: 120
- Hertz: 50/60
- Watts: 110
- Amperage: 0.88
- Phase: Single
- RPM: 5000
- Electronically Protected
- Insulation Class: B
- Motor Cooling: Air Over
- Bearings: Sealed Ball
- Rotation: Clockwise Lead End
- CONTROLLER
- Controller Type: SD01
- Controller Number: 81104165
- Voltage: 120 VAC
- Amperage: 1.64
- Watts: 110
Replaces Old Carrier Part Numbers
- 324906-762
- 320727-755
- 320727-754
- 320727-753
- 320727-752
- 320727-751
- 322550-702
- 324906-701
- 324906-702
- HC23CE115
- HC23CE116
Other Part Numbers
340793762, Replacement Components Division, Factory Authorized Parts, Carrier Corporation, 340793-762, Inducer Kit, VS, 0 08 22529 66208 4, L/15, 2.80-3.08in, 71.1-78.2mm, HR46GH003, 65217, 81104165, Controller Type SD01, 4515N30464341064-402, REV. B, Electronically Protected, Fasco, 71500178, 8534-4102, 50FA Class B, HC24CN115, 339711-401, 319824-403 E, IK---340793---762---01
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
58MVB, 58UVB PG9UAA Series, 355AAV042040FCSA 355AAV042060FCSA 355AAV042080FCSA 355AAV060080FCSA 355AAV060100FCSA 355AAV060120FCSA 355BAV042060ACSA 355BAV042080ACSA 355BAV060080ACSA 355BAV060100ACSA 355BAV060120ACSA 355CAV042060FASA 355CAV042080FASA 355CAV060080FASA 355CAV060100FASA 355CAV060120FASA 58MVB040-F-10114 58MVB040-F-11114 58MVB040-F-12114 58MVB060-F-10114 58MVB060-F-11114 58MVB060-F-12114 58MVB080-F-10114 58MVB080-F-10120 58MVB080-F-11114 58MVB080-F-11120 58MVB080-F-12114 58MVB080-F-12120 58MVB100-F-10120 58MVB100-F-11120 58MVB100-F-12120 58MVB120-F-10120 58MVB120-F-11120 58MVB120-F-12120 58MVC060-F-10114 58MVC080-F-10114 58MVC080-F-10120 58MVC080-L-10114 58MVC100-F-10120 58MVC120-F-10120 58UVB060---12114 58UVB080---12114 58UVB080---12120 58UVB100---12120 58UVB120---12120 PG9UAA042060AASA PG9UAA042080AASA PG9UAA060080AASA PG9UAA060100AASA PG9UAA060120AASA
4 Reviews
-
Quick Shipping / Heats Back On
This part died and our local HVAC company couldn't get there hands on one (backordered at the factory). Called up THC to verify this was actually in stock; they confirmed their distributor had one and it'd be shipped to them (3-5 days) then to me. Luck has it they shipped it next day and we had it 4 business days later! Local company just installed it, no issues. Even saved a few hundred bucks. Installation looked pretty straight forward and doable for the DIY'r. (took HVAC guy 30 minutes).
-
correct for carrier 58mvc
Took an hour and change to swap. Half the time was screwing around with the bottom left mounting bolt. Tolerances are inadequate for normal drivers. Gotta Rube Goldberg bits and extensions together to get it. Also, take care in lining up the housing with the triangle gasket. Carrier dealer wanted 400 in labor to do it so still totally worth it. Now I've got heat and I'm not listening to grinding bearings on the HC23CE116 this replaced.
-
Inducer
Perfect fit. Will use THC again
-
Cheaper than a new furnace
Don't get me wrong, this part is expensive, but it fixed my problem and Technical Heating and Cooling had to my house next day and it was cheaper than anyone other website I would trust. I just hope the new one lasts longer than the old one did.
