Carrier 342813-75101 Replacement Part
Includes:
- (1) - Evaporator Coil w/ TXV (342813-75101)
- (1) - Distributor Adapter (-)
- (2) - Washer (-)
- (2) - Zip Tie (-)
- (2) - Insulation Foam (-)
- (1) - Installation Instructions (IIK-LRCOIL-02)
Specifications
- Style: A-Coil
- Number of Rows: 3
- Fins per Inch: 14
- Refrigerant: 410a
- Inlet 3/8"
- Outlet: 3/4"
- Dimensions: 20 1/2" x 15" x 15 1/2"
- TXV Model Number: EA36YP271
Replaces Old Carrier Part Numbers
- 340155-7031
- 326385-770
- 316822-770
- 324390-701
- 326385-781
- 340155-7011
- 340155-7016
Other Part Numbers
REPLM Coil Kit, Factory Authorized Parts, Replacement Components Division, Carrier Corporation, C/8, 00822529818740, 9345/9328, 339759-701, 009000591137, RF1, RC#, 339494-713, 339799-713, A-COIL KIT, RPLCMNT
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
FE4ANF002L00EBAA, FE4ANF002L00ECAA, FV4CNF002L00EBAA, FV4CNF002L00ECAA, FV4CNF002LC0ECAA
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
1 Review
-
Carrier 342813-75101 Evaporator Coil
This Evaporator Coil was made superior to the original one that I replaced in my Carrier Air Handler. The replacement was constructed from aluminum and the original from tin. After ten years it had to be replaced.
