Carrier HB33GR236 Replacement Part
NOTE: THIS PART IS NO LONGER AVAILABLE. IT HAS BEEN REPLACED BY PART # HB33GQ231
Includes:
- (1) - Fan Motor (HB33GR236)
Specifications
- Manufacturer: genteq
- Model # 5KCP39CGSA37S
- Horsepower: 1/10
- Voltage: 208/230
- Hertz: 60
- Amperage: 0.75
- Phase: Single
- RPM: 1100
- Speeds: 1
- Frame: 39
- Thermally Protected
- Insulation Class: B
- Motor Cooling: Continuous Air Over
- Capacitor Needed: 5 MFD @ 370 VAC
- Rotation: Clockwise Lead End
- Shaft Type: Single Side Flat Shaft
- Shaft Diameter: 1/2"
- Shaft Length: 2 1/2"
Country of Origin: Mexico
Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure due to vibration. If you are not sure what fan blade fits your fan assembly, call us at 734-326-3900.
🚀 To prevent premature motor failure, it is highly recommended you change your capacitor along with your motor. Capacitors out of tolerance can cause motors to overheat and prematurely fail. If you are unsure of what capacitor is required for your unit, please call us at 734-326-3900.
Replaces Old Carrier Part Numbers
- HC33GE236
Other Part Numbers
Motor, Fan, 1/10hp, 5KCP39CGSA37S, A16V, 5KCP39CG, SA37S, Replacement Components Division, Factory Authorized Parts, HB 33GR 236, Carrier Corporation, I16V
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
105ANA030000BAAA, 105ANA030000BAAB, 106ANA030000BAAA, 106ANA030000BAAB, 114CNA030000BAAA, 114CNA030000BAAB, 114CNC030000BAAA, 114CNC036000BAAA, 116BNA024000BAAB, 116BNA030000BAAB, 214DNC030000BAAA, 24AAA530A0030010, 24AAA530A0030011, 24AAA630A0030010, 24AAA630A0030011, 24ABC624A0030011, 24ABC630A0030011, 24ACA430C0030010, 24ACA436C0030010, 24ACC430A0030010, 24ACC430A0030011, 25HCE430C0030010, BA14NA03000GAAAA, BA15NA03000GAAAA, BA16NA02400GAAAA, BA16NA03000GAAAA, BA16NW03000GAAAA, BH14NA02400GAAAA, BH14NA03000GAAAA, BH14NA04200GAAAA, CA14NA03000GAAAA, CA15NA03000GAAAA, CA16NA02400GAABA, CA16NA03000GAABA, CA16NW03000GAAAA, CH13NA02500GABBA, CH13NA03100GABBA, CH13NA04300GABAA, CH13NA04300GABBA, CH14NA02400GAAAA, CH14NA03000GAAAA, CH14NA04200GAAAA, PA14NC030000AAAA, PA14NC03000GAAAA, PA15NC030000AAAA, PA15NC03000GAAAA, PA16NW03000GAAAA, PH13NB04300GAAAA, PH13PR03000GALAA
