Carrier HC35SL231 Replacement Part
Includes:
- (1) - Fan Motor with Rain Guard (HC35SL231)
- (3) - Insulated Quick Connections (-)
- (1) - Instructions (99TA506104 Rev. A)
Specifications
- Manufacturer: genteq
- Model # 5KCP39FFM592S
- Horsepower: 1/8
- Voltage: 208-230
- Hertz: 60
- Amperage: 0.90
- Phase: Single
- RPM: 850
- Frame: 48
- Thermally Protected
- Insulation Class: B
- Motor Duty/Cooling: Continuos Air Over
- Bearings: Sleeve
- Mount: Belly Band
- Capacitor Needed: 5 MFD @ 370 VAC
- Rotation: Counterclockwise Lead End
- Shaft Type: Single Side Flat Shaft
- Shaft Diameter: 1/2"
- Shaft Length: 3 1/2"
Note: Always check the fan blade on your fan assembly. Bad or unbalanced fan blades can cause premature motor failure due to vibration. If you are not sure what fan blade fits your fan assembly, call us at 734-326-3900.
🚀 To prevent premature motor failure, it is highly recommended you change your capacitor along with your motor. Capacitors out of tolerance can cause motors to overheat and prematurely fail. If you are unsure of what capacitor is required for your unit, please call us at 734-326-3900.
Replaces Old Carrier Part Numbers
- HC35SL226
- HC35SL230
- HC33SL230
Other Part Numbers
5KCP39FFM592 S, 5KCP39FF, M592S, CPNHC35SL231, HC 35SL 231, E127Y1868990, 1004860 000110, 24X327056, E11V, 0 06 62441 15222 1, genteq, ASSM IN MEXICO, G14V Thermally Protected, CSA, RU
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
38EHX018---300--, 38EHX018---310--, 38EHX030---310--, 38EH-015---300DL, 38EH-015---300SM, 38EH-015---300--, 38EH-015---310SM, 38EH-015---310--, 38EH-015---320CL, 38EH-018---300CD, 38EH-018---300DL, 38EH-018---300SM, 38EH-018---300--, 38EH-018---310DL, 38EH-024---300CD, 38EH-024---300DL, 38EH-024---300SM, 38EH-024---300--, 38EH-024---310DL, 38EH-024---320DL, 38EH-024---320--, 38EH-030---300CD, 38EH-030---300DL, 38EH-030---300SM, 38EH-030---300--, 38EH-030---310--, 38EH-030---320SM, 38EH-030---320--, 38EH-030---340DL, 38EH-030---340--, 38EH-036---300CD, 38EH-036---300DL, 38EH-036---300SM, 38EH-036---300--, 38EH-036---330DL, 38EH-036---350DL, 38EH-036---350SM, 38EH-036---350--, 38EH-036---360DL, 38EH-036---360--, 38EH-036---520DL, 38EH-036---520SM, 38EH-036---560DL, 38EH-036---560--, 38EH-042---300CD, 38EH-042---300DL, 38EH-042---300SM, 38EH-042---300--, 38EH-042---310DL, 38EH-042---320DL, 38EH-042---320--, 38EH-042---500DL, 38EH-042---500SM, 38EH-042---510DL, 38EH-042---520DL, 38EH-042---520--, 38ER-018---300--, 38ER-024---300--, 38ER-030---300--, 38ER-036---300--, 38ER-036---500--, 38ER-042---300--, 38ER-042---500--, 38ES-018---300CD, 38ES-018---300DL, 38ES-018---300SM, 38ES-018---300--, 38ES-024---300CD, 38ES-024---300DL, 38ES-024---300SM, 38ES-024---300--, 38ES-030---300--, 38ES-030---310DL, 38ES-030---310SM, 38ES-030---310--, 38ES-030---320DL, 38ES-030---330DL, 38ES-036---300CD, 38ES-036---300DL, 38ES-036---300SM, 38ES-036---300--, 38ES-036---310DL, 38ES-042---300CD, 38ES-042---300DL, 38ES-042---300SM, 38ES-042---300--, 38ES-042---310DL, 38EV-024---320--, 38EV-036---320--, 38LE-018---300CD, 38LE-018---310CD, 38LE-018---320--, 38LE-024---300CD, 38LE-024---310CD, 38LE-024---320--, 38LE-030---300CD, 38LE-030---310CD, 38LE-030---320--, 38LE-036---300CD, 38LE-036---310CD, 38LE-042---300CD, 38LE-042---310CD, 38QHX018---300--, 38QHX030---300--, 38QH-015---300BA, 38QH-015---300CD, 38QH-015---300DL, 38QH-015---300SM, 38QH-015---300--, 38QH-018---300BA, 38QH-018---300CD, 38QH-018---300DL, 38QH-018---300MX, 38QH-018---300SM, 38QH-018---300--, 38QH-018---310DL, 38QH-018---310--, 38QH-024---300CD, 38QH-024---300DL, 38QH-024---300SM, 38QH-024---300--, 38QH-024---310DL, 38QH-024---310--, 38QH-030---300CD, 38QH-030---300DL, 38QH-030---300MX, 38QH-030---300SM, 38QH-030---300--, 38QH-030---310DL, 38QH-030---310--, 38QH-030---500DL, 38QH-030---500SM, 38QH-030---510DL, 38QH-030---510--, 38QH-036---300CD, 38QH-036---300DL, 38QH-036---300SM, 38QH-036---300--, 38QH-036---500DL, 38QH-036---500SM, 38QN-015---320--, 38QN-018---330--, 38QN-036---310--, 38QN-036---510--, 38QV-024---320--, 38QV-036---320--, 77QA-015---300--, 77QA-018---300--, 77QA-036---300--
