ICP 1085645 Replacement Part
Includes:
- (1) - Blower Motor (1085645)
Specifications
- Manufacturer: US Motors
- Model # K55HXFRA-7882
- Horsepower: 1.0
- Voltage: 460
- Hertz: 60
- Full Load Amperage: 2.10
- Phase: Single
- RPM: 1000
- Speeds: 3
- Frame: 48Y
- Thermally Protected
- Insulation Class: B
- Motor Cooling: Air Over Continuous
- Bearings: Sleeve
- Enclosure: Open
- Rotation: Counterclockwise Lead End
- Capacitor Needed: 20 MFD @ 370 VAC
- Shaft Type: Double Sided Flat Shaft
- Shaft Diameter: 5/8"
- Shaft Length: 5"
Note: Always check the blower wheel on your blower assembly. Bad or unbalanced blower wheels can cause premature motor failure due to vibration. If you are not sure what blower wheel fits your blower assembly, call us at 734-326-3900.
Replaces Old ICP Part Numbers
- There are no older part numbers.
Other Part Numbers
K55HXFRA-7882, K55HXFRA7882, Fast HVAC PARTS, OEM Parts, 1085645, Blower Motor, F16C, 156060, 0181155160985,
Fits ICP, Heil, Tempstar, Arcoaire, Comfortmaker, Snyder General, KeepRite and Day & Night Models:
(Press ctrl + F to find model number below.)
APFM48L000A, APFM48L000E, APFM60L000A, APFM60L000B, APFM60L000E, HPFM48L000A, HPFM48L000E, HPFM60L000A, HPFM60L000E, PAF048L000A, PAF048L000E, PAF060L000A, PAF060L000B, PAF060L000E, PGAD47F1LB, PGAD47F1LD, PGAD48F1LE, PGB048F1LD, PGB048F1LE, PGCD48F120E, PGCD48F1LE, PGME48F120E, PGME48F135B, PGME48F135D, PGME48F135E, PGMF48F135D, PGMF48F135E, PHF048L000A, PHF048L000E, PHF060L000A, PHF060L000E,
