Carrier OPNDR08ZC Replacement Part
Includes:
- (1) - 8" Round Zone Damper (OPNDR08ZC)
- (1) - Electrical Box Cover (-)
- (1) - Electrical Cover Screw (-)
- (1) - O-Ring (-)
Specifications
- Purpose: VVT Round Zone Damper with VVT Zone II Controller Sued in Carrier's i-Vu Building Automation System
- The Factory Integrated VVT Zone Controls Maintains Space Temperature By Modulating the Proper Amount of Supply Airflow Through Its Damper
- VVT ZONE DAMPER (ROUND)
- CFM Airflow Min/Max: 280/420
- Comes with Integral Supply Air Temperature Sensor
- Demand Control Ventilation Sensor Input Point
- Counterclockwise and Clockwise Damper Rotation
- Configurable Min and Max Open Damper Positions
- Optional 0-10VDC Output for Linking Actuators
- Degree of Rotation: 30-90
- Pressure Rating: 1" wg Static Pressure
- Housing: 24 Gauge Spiral Metal Duct
- Elliptical Damper Blade: 20 Gauge
- Length: 18"
- Diameter: 8"
- VVT ZONE CONTROLLER
- Separable Actuator with Brushless DC Motor
- Runtime: 205 Seconds for 90° Travel During Control
- Provides Pressure Dependent (VVT), Space Temperature Control for Terminals Up To 2.7 Square Ft Inlet
- Provides Zone Level Humidty Control OR Zone Level Demand Control Ventilation (ASHRAE 62), With Field-Installed Sensor
- Provides PID Control
- Optional Terminal Fan or Auxilary Heat Control
- Provides Remote Occupancy Contact Input for Field-Installed Occupancy Sensor
- Supports Sensor Averaging
- Capable of Stand-Alone Operation with Integral Supply Air Temperature Sensor
- Air Balancing Tool Available
- Controller Network is BACnet MS/TP @ 9600bps, 19.2 kbps, 38.4 kbps, or 76.8 kbps or ARCNET 156 kbps
- i-VU Can Be Used to Access Controller Both Locally and Remotely
- 22/24 AWG Communications Wiring: Single Twisted Shielded Pair, Low Capacitance, CL2P Wire
- Power Requirements: 24 VAC +/- 10%, 50/60 Hz, 14 VA Power Consumption, 26 VDC (25V min, 30V Max), Single Class 2 Source Only, 100 VA or Less
- Power Wiring: 2 Conductor, 18 AWG, Unshielded
- Operating Range: 32°F to 130°F (0°C to 54°C), 10 to 90% RH, Non-Condensing
Country of Origin: USA
Replaces Old Carrier Part Numbers
- There are no older part numbers.
Other Part Numbers
OPNDR08ZC, , Round Zone Damper , with VVT Zone II Controller, Carrier, United Technologies, LMB24-MPL-ALC, 260530, 0101, 21306540-040242, 781897 193
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
i-Vu® Building Automation System
