Hoffman (nVent) ABL Small Handle Operator Adapter Kit

Includes:

• (1) - Small Adpater Plate (87951268)
• (1) - Plate Gasket (89109613)
• (4) - 1/4-20x1/2" Pan Head Screw (99401031)
• (1) - Flat Slide Arm (26250001)
• (1) - 5/8" Shoulder Collar (26149001)
• (1) - 1/4-20x7/8" Hex Head Screw (99401030)
• (1) - 1/4" Spring Lock Washer (99401318)
• (2) - Flat Washer (22101003)
• (2) - 1/4" Internal Teeth Lock Washer (99401300)
• (2) - 1/4-20 Hex Nut (99401406)
• (1) - Door Catch (23101002)
• (2) - 10-32x3/8" Pan Head Screw (99401007)
• (2) #10 Internal Tee Lock Washer (99401307)
• (4) - Nylon Washer (26132003)
• (1) - Installation Instructions (89114650)

Specifications:

• Used on all Hoffman Type 4 and 12 disconnect enclosures with a universal flange cutout
• An operator adapter is required to install a disconnect in Bulletin A21, A28, A34 and A4L3D Hoffman enclosures that have a universal cutout
• A 200A (or less) disconnect switch and 400A (or less) circuit breaker require a small handle

Replaces Old Hoffman (nVent) Part Numbers:

• There are no older part numbers.

Other Part Numbers:

For use with small handle disconnect switches, 1494V, 1494C, 140G, 140U, Hoffman, 28087, ABS, AB Small Handle Adpater Plate, A21ABVA, Hoffman, Pentair, APW, McLean, nvent

Fits Models:(Press ctrl + F to find model number below if you have any questions call 734-326-3900 for further information)

Allen-Bradley 1494V, 1494C, 140G, 140U

If you have any questions or would like to confirm part fitment, please call us at (734) 326-3900 and speak with one of our technicians.
