Hoffmann Filter Corporation 69-153056 Replacement Part
Includes:
- (1) - Condenser Fan Motor Assembly (69-153056)
Specifications
- Manufacturer: Ziehl-Abegg Model: FN050-VDK.4I.V7P1 Motor Type: 3-phase (3~) AC Fan Type: Axial fan Insulation Class: THCL 166 (thermal class, 166 °C max winding temperature) Protection Rating: IP54 (dust protected, splash resistant) Duty: Continuous Ambient Temperature Rating: Up to 70 °C DI: 0% (no speed control / no inverter duty specified) Wiring Type: Delta (Δ / D) and Star (Y)
- 400 V ±10%, 60 Hz Voltage (Delta): 400 V Voltage (Star): 400 V Frequency: 60 Hz Power Input P1 (Delta): 0.77 kW Power Input P1 (Star): 0.49 kW Current (Delta): 1.7 A Current (Star): 0.84 A Speed (Delta): 1300 RPM Speed (Star): 1026 RPM Power Factor cos (Delta): 0.84 Power Factor cos (Star): 0.84 Maximum Ambient Temperature: 70C
- 400 V ±10%, 50 Hz Voltage (Delta): 400 V Voltage (Star): 400 V Frequency: 50 Hz Power Input P1 (Delta): 1.10 kW Power Input P1 (Star): 0.60 kW Current (Delta): 1.9 A Current (Star): 1.0 A Speed (Delta): 1400 RPM Speed (Star): 980 RPM Power Factor cos (Delta): 0.81 Power Factor cos (Star): 0.81 Maximum Ambient Temperature: 70C
- 480 V ±10%, 60 Hz Voltage (Delta): 480 V Voltage (Star): 480 V Frequency: 60 Hz Power Input P1 (Delta): 1.20 kW Power Input P1 (Star): 0.70 kW Current (Delta): 2.0 A Current (Star): 1.06 A Speed (Delta): 1480 RPM Speed (Star): 1100 RPM Power Factor cos φ (Delta): 0.76 Power Factor cos φ (Star): 0.76 Maximum Ambient Temperature: 70C
Replaces Old Hoffmann Filter Corporation Part Numbers
- There are no older part numbers.
Other Part Numbers
Ziehl-Abegg, 33462714/031
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
