Honeywell Q3400A1024 Ignitor and Flame Sensor Assembly

Includes:

• (1) - Ignitor and Flame Sensor Assembly (Q3400A1024)
• (1) - Clip (393939-1)
• (1) - Instructions (69-0751-2)

Specifications:

• Style: 45°
• Flame Sensor Length:
• Overall length - 1 1/8"
• Igniter element Length: 11/16"
• Length to L: 9/16"
• Length to End: 5/8"
• Bracket Length: 1"
• Igniter Type: Silicon-Nitride
• Lead Length: 31"

Country of Origin: Mexico

Replaces Old Honeywell Part Numbers:

• Q3400A1016
• Q3400A1008

Other Part Numbers:

For Q3450 Q3620 Q3480 Field Replacements Honeywell Replace with Q3400A 1024, 1442, 1834, 393939-1, SV9510, SV9601, SV9502, SV9602, SV9540, SV9640, SV9541, SV9641, 180825, 51360, 00662442326614, 662442, 326614, 085267780377, 85267, 78037, D6, 1834D6,

Fits Models:(Press ctrl + F to find model number below if you have any questions call 734-326-3900 for further information)

Various. (Call 734-326-3900 with your model and serial number for more information.)

If you have any questions or would like to confirm part fitment, please call us at (734) 326-3900 and speak with one of our technicians.
