Hyfra 49155 Replacement Part
CALL (734) 326-3900 or SEND MESSAGE TO PARTS@TECHNICALHOTANDCOLD.COM FOR PRICE!
Includes:
- (1) - Pump Assembly (49155)
Specifications
- Manufacturer: Grundfos Series: CM Pump Type: Horizontal Multistage Centrifugal Pump Model: CM1-4 A-R-A-V-AQQV J-A-A-N Grundfos Model Number: 97689064 Motor Power: 0.83 HP (0.62 kW) Voltage: 440-480 VAC Phase: 3-Phase Frequency: 60 Hz Speed: 3220-3380 RPM Full Load Current: 1.7-1.6 A Insulation Class: F Maximum Liquid Temperature: 194F (90C) Maximum Ambient Temperature: 131F (55C) Maximum Working Pressure: 145 PSI (10 bar / 1.0 MPa) Nominal Flow (60 Hz): 2.0 m³/h (9.0 GPM) Nominal Head (60 Hz): 35.4 m (50.4 PSI / 116 ft) Maximum Head (60 Hz): 51.7 m (73.6 PSI / 169.6 ft) Nominal Flow (50 Hz): 1.7 m³/h (7.5 GPM) Nominal Head (50 Hz): 24.6 m (35.0 PSI / 80.7 ft) Maximum Head (50 Hz): 35.9 m (51.1 PSI / 117.8 ft) Maximum Efficiency Index (MEI): ≥ 0.7 Country of Manufacture: Hungary
Replaces Old Hyfra Part Numbers
- There are no older part numbers.
Other Part Numbers
Grundfos CM1-4 A-R-A-V-AQQV J-A-A-N,
