Lahntechnik Duotemp 112674 Replacement Part
CALL (734) 326-3900 or SEND MESSAGE TO PARTS@TECHNICALHOTANDCOLD.COM FOR PRICE!
Includes:
- (1) - Load Switch 16A (112674)
- (1) - Terminal Cover
- (1) - Instructions
- (4) - Screws
Specifications
- Brand: Siemens Series: SENTRON 3LD Model: 3LD2003-0TK51 Product Type: Switch Disconnector / Main Switch Pole Configuration: 3 Pole Rated Operational Current: 16 A Rated Insulation Voltage: 690 V Rated Operating Voltage: Up to 690 VAC Frequency: 50/60 Hz Surge Voltage Rating: 6 kV Utilization Category AC-21A: 16 A at 240–690 V Utilization Category AC-23A: 16 A at 400 V Motor Rating AC-3: 3 kW at 240 V 6 kW at 400 V 5.5 kW at 690 V Power Rating AC-23A: 4 kW at 240 V 7.5–8 kW at 400–690 V Conditional Short Circuit Current: 50 kA with gG fuse Recommended Fuse: 20 A Short-Time Withstand Current: 340 A for 1 second SCCR UL: 5 kA at 600 V Mechanical Life: 100,000 operations Electrical Life: 6,000 operations at AC-23A 690 V Max Switching Frequency: 50 operations per hour Operation Type: Manual rotary ON/OFF
- Mounting Type: Front mount 4-hole Handle Type: Short rotary knob Handle Color: Black Device Type: Fixed-mounted Terminal Type: Box terminals Lockable: Yes up to 3 padlocks in OFF position
- Solid Conductors: 1–6 mm(squared) Stranded Conductors: 1–6 mm(squared) Fine Stranded with Ferrule: 1–4 mm(squared)
- IP Rating: IP65 front NEMA Rating: 1 3R 4X 12 Pollution Degree: 3 -25C to +55C Storage Temperature: -25C to +55C
- Height: 84 mm Width: 67 mm Depth: 93 mm Weight: 0.2 kg
Replaces Old Lahntechnik Duotemp Part Numbers
- There are no older part numbers.
Fits Models:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
Technical Hot & Cold honors all manufacturer warranties and offers a 1-year warranty on non-maintenance items.
