Lennox 60M12 Contactor

No reviews yet Write a Review
$104.52
SKU:
60M12
Condition:
New
Weight:
3.00 LBS
Amps:
25
  • Technical Hot & Cold BBB Business Review

Lennox 60M12 Contactor

$104.52
  • Part Info & Specifications

  • Includes:

    • (1) - Contactor (60M12)

    Specifications:

    • Manufacturer: Hartland Controls
    • Series: HCC
    • Model # HCC-3XQ01HA106
    • Type: Definite Purpose
    • # of Poles: 3
    • Switch Type: Three-Pole Single-Throw
    • Circuit: Normally Open
    • Max Voltage: 600
    • Coil Terminal Connections: 1/4" Quick Connect
    • COIL VOLTAGE
    • VAC: 24
    • Hertz: 50/60
    • LINE VOLTAGE
    • Voltage: 120 (Single-Phase)
    • Horsepower: 2.0
    • Full Load Amperage: 25
    • Resistance: 35 Ohms
    • Voltage: 240 (Single-Phase)
    • Horsepower: 5.0
    • Full Load Amperage: 25
    • Locked Rotor Amperage: 150
    • Resistance: 35 Ohms
    • Voltage: 240 (3-Phase)
    • Horsepower: 7.5
    • Full Load Amperage: 25
    • Locked Rotor Amperage: 150
    • Resistance: 35 Ohms
    • (ABOVE 240V BREAK ALL LINES)
    • Voltage: 480 (3-Phase)
    • Horsepower: 15.0
    • Full Load Amperage: 25
    • Locked Rotor Amperage: 125
    • Resistance: 35 Ohms
    • Voltage: 600 (3-Phase)
    • Horsepower: 20.0
    • Full Load Amperage: 25
    • Locked Rotor Amperage: 100
    • Resistance: 35 Ohms

    Country of Origin: China

    Replaces Old Lennox Part Numbers:

    • 60M1201

    Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:

    • 60M1201

    Other Part Numbers:

    S: C 1544-095349 K, HCC-3XQ01HA106, Definite Purpose Contactor, 25 FLA 35A RES, Herm. Refrig. Comp., 1720-175009, Hartland Controls, 60M12

    Fits Models:(Press ctrl + F to find model number below if you have any questions call 734-326-3900 for further information)

    KCA036S4-1, KCA036S4-2, KCA036S4-3, KCA048S4-1, KCA048S4-2, KCA048S4-3, KCA060S4-1, KCA060S4-2, KCA060S4-3, KCA060S4-4, KCA092H4-1, KCA092H4-2, KCA092S4-1, KCA092S4-2, KCA092S4-3, KCA102H4-1, KCA102H4-2, KCA102S4-1, KCA102S4-2, KCA102S4-3, KCA120H4-1, KCA120S4-1, KCA120S4-2, KCA120S4-3, KCA150S4-1, KCA150S4-2, KCA150S4-3, KCB036S4-1, KCB048S4-1, KCB060S4-1, KDB036H4-1, KDB048H4-1, KDB060H4-1, KDB092H4-1, KDB102H4-1, KDB122H4-1, KGA036S4-1, KGA036S4-2, KGA036S4-3, KGA036S4-4, KGA048S4-1, KGA048S4-2, KGA048S4-3, KGA048S4-4, KGA060S4-1, KGA060S4-2, KGA060S4-3, KGA060S4-4, KGA060S4-5, KGA072S4-1, KGA072S4-2, KGA072S4-3, KGA072S4-4, KGA090S4-1, KGA090S4-2, KGA090S4-3, KGA090S4-4, KGA092H4-1, KGA092H4-2, KGA092S4-1, KGA092S4-2, KGA092S4-3, KGA102H4-1, KGA102H4-2, KGA102S4-1, KGA102S4-2, KGA102S4-3, KGA120H4-1, KGA120S4-1, KGA120S4-2, KGA120S4-3, KGA150S4-1, KGA150S4-2, KGA150S4-3, KGB036S4-1, KGB048S4-1, KGB060S4-1, KGB072H4-1, KGB074H4-1, KGB074S4-1, KHA036S4-1, KHA036S4-2, KHA048S4-1, KHA048S4-2, KHA060S4-1, KHA060S4-2, KHA092S4-1, KHA102S4-1, KHA120S4-1, KHA150S4-1, KHB036S4-1, KHB048H4-1, KHB048S4-1, KHB060H4-1, KHB060S4-1, KHB092H4-1, KHB102H4-1, KHB122H4-1, LCH036H4-1, LCH036H4-2, LCH036H4-3, LCH036S4-1, LCH036S4-2, LCH036S4-3, LCH036U4-1, LCH048H4-1, LCH048H4-2, LCH048H4-3, LCH048U4-1, LCH048S4-1, LCH048S4-2, LCH048S4-3, LCH060H4-1, LCH060H4-2, LCH060H4-3, LCH060S4-1, LCH060S4-2, LCH060S4-3, LCH060U4-1, LCH072H4-1, LCH072H4-2, LCH072H4-3, LCH074H4-1, LCH074U4-1, LCH092H4-1, LCH092H4-2, LCH092H4-3, LCH094U-1, LCH102H4-1, LCH102H4-2, LCH102H4-4, LCH120H4-1, LCH120H4-2, LCH120H4-3, LCH122U-1, LCH150S4-1, LCH150S4-2, LCH150S4-3, LCH150S4-4, LCH152U-1, LGH036H4-1, LGH036H4-2, LGH036H4-3, LGH036H4-4, LGH036S4-1, LGH036S4-2, LGH036S4-3, LGH036S4-4, LGH036U4-1, LGH048H4-1, LGH048H4-2, LGH048H4-3, LGH048H4-4, LGH048S4-1, LGH048S4-2, LGH048S4-3, LGH048S4-4, LGH048U4-1, LGH060H4-1, LGH060H4-2, LGH060H4-3, LGH060H4-4, LGH060S4-1, LGH060S4-2, LGH060S4-3, LGH060S4-4, LGH060U4-1, LGH072H4-1, LGH072H4-2, LGH072H4-3, LGH072H4-4, LGH074H4-1, LGH074U4-1, LGH092H4-1, LGH092H4-2, LGH092H4-3, LGH094U4-1, LGH102H4-1, LGH102H4-2, LGH102H4-3, LGH120H4-1, LGH120H4-2, LGH120H4-3, LGH122U4-1, LGH150S4-1, LGH150S4-2, LGH150S4-3, LGH150S4-4, LGH152U4-1, SCC120H4-1, SGC120H4-1, TCA036B2-1, TCA036S2-1, TCA048B2-1, TCA048S2-1, TCA060B2-1, TCA060S2-1, TCA090H2-1, TCA090S2-1, TCA102H2-1, TCA102S2-1, TCA120H2-1, TCA120S2-1, TCA150S2-1, TGA036B2-1, TGA036S2-1, TGA048B2-1, TGA048S2-1, TGA060B2-1, TGA060S2-1, TGA072S2-1, TGA090H2-1, TGA090S2-1, TGA102H2-1, TGA102S2-1, TGA120H2-1, TGA120S2-1, TGA150S2-1, THA036B2-1, THA036S2-1, THA048B2-1, THA048S2-1, THA060B2-1, THA060S2-1, THA090S2-1, THA090S2-2, THA090S2-3, THA102S2-1, THA102S2-2, THA102S2-3, THA120S2-1, THA120S2-2, THA120S2-3, THA150S2-1, THA150S2-2, THA150S2-3, TPA090S4S-1, TPA120S4S-1, TSA072S4-1, TSA090S4-1, TSA120S4S-1

    Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:(Press ctrl + F to find model number below if you have any questions call 734-326-3900 for further information)

    KCA036S4-1, KCA036S4-2, KCA036S4-3, KCA048S4-1, KCA048S4-2, KCA048S4-3, KCA060S4-1, KCA060S4-2, KCA060S4-3, KCA060S4-4, KCA092H4-1, KCA092H4-2, KCA092S4-1, KCA092S4-2, KCA092S4-3, KCA102H4-1, KCA102H4-2, KCA102S4-1, KCA102S4-2, KCA102S4-3, KCA120H4-1, KCA120S4-1, KCA120S4-2, KCA120S4-3, KCA150S4-1, KCA150S4-2, KCA150S4-3, KCB036S4-1, KCB048S4-1, KCB060S4-1, KDB036H4-1, KDB048H4-1, KDB060H4-1, KDB092H4-1, KDB102H4-1, KDB122H4-1, KGA036S4-1, KGA036S4-2, KGA036S4-3, KGA036S4-4, KGA048S4-1, KGA048S4-2, KGA048S4-3, KGA048S4-4, KGA060S4-1, KGA060S4-2, KGA060S4-3, KGA060S4-4, KGA060S4-5, KGA072S4-1, KGA072S4-2, KGA072S4-3, KGA072S4-4, KGA090S4-1, KGA090S4-2, KGA090S4-3, KGA090S4-4, KGA092H4-1, KGA092H4-2, KGA092S4-1, KGA092S4-2, KGA092S4-3, KGA102H4-1, KGA102H4-2, KGA102S4-1, KGA102S4-2, KGA102S4-3, KGA120H4-1, KGA120S4-1, KGA120S4-2, KGA120S4-3, KGA150S4-1, KGA150S4-2, KGA150S4-3, KGB036S4-1, KGB048S4-1, KGB060S4-1, KGB072H4-1, KGB074H4-1, KGB074S4-1, KHA036S4-1, KHA036S4-2, KHA048S4-1, KHA048S4-2, KHA060S4-1, KHA060S4-2, KHA092S4-1, KHA102S4-1, KHA120S4-1, KHA150S4-1, KHB036S4-1, KHB048H4-1, KHB048S4-1, KHB060H4-1, KHB060S4-1, KHB092H4-1, KHB102H4-1, KHB122H4-1, LCH036H4-1, LCH036H4-2, LCH036H4-3, LCH036S4-1, LCH036S4-2, LCH036S4-3, LCH036U4-1, LCH048H4-1, LCH048H4-2, LCH048H4-3, LCH048U4-1, LCH048S4-1, LCH048S4-2, LCH048S4-3, LCH060H4-1, LCH060H4-2, LCH060H4-3, LCH060S4-1, LCH060S4-2, LCH060S4-3, LCH060U4-1, LCH072H4-1, LCH072H4-2, LCH072H4-3, LCH074H4-1, LCH074U4-1, LCH092H4-1, LCH092H4-2, LCH092H4-3, LCH094U-1, LCH102H4-1, LCH102H4-2, LCH102H4-4, LCH120H4-1, LCH120H4-2, LCH120H4-3, LCH122U-1, LCH150S4-1, LCH152U-1, LGH036H4-1, LGH036H4-2, LGH036H4-3, LGH036H4-4, LGH036S4-1, LGH036S4-2, LGH036S4-3, LGH036S4-4, LGH036U4-1, LGH048H4-1, LGH048H4-2, LGH048H4-3, LGH048H4-4, LGH048S4-1, LGH048S4-2, LGH048S4-3, LGH048S4-4, LGH048U4-1, LGH060H4-1, LGH060H4-2, LGH060H4-3, LGH060H4-4, LGH060S4-1, LGH060S4-2, LGH060S4-3, LGH060S4-4, LGH060U4-1, LGH072H4-1, LGH072H4-2, LGH072H4-3, LGH072H4-4, LGH074H4-1, LGH074U4-1, LGH092H4-1, LGH092H4-2, LGH092H4-3, LGH094U4-1, LGH102H4-1, LGH102H4-2, LGH102H4-3, LGH120H4-1, LGH120H4-2, LGH120H4-3, LGH122U4-1, LGH150S4-1, LGH150S4-2, LGH150S4-3, LGH150S4-4, LGH152U4-1, SGC120H4-1, TCA036B2-1, TCA036S2-1, TCA048B2-1, TCA048S2-1, TCA060B2-1, TCA060S2-1, TCA090H2-1, TCA090S2-1, TCA102H2-1, TCA102S2-1, TCA120H2-1, TCA120S2-1, TCA150S2-1, TGA036B2-1, TGA036S2-1, TGA048B2-1, TGA048S2-1, TGA060B2-1, TGA060S2-1, TGA072S2-1, TGA090H2-1, TGA090S2-1, TGA102H2-1, TGA102S2-1, TGA120H2-1, TGA120S2-1, TGA150S2-1, THA036B2-1, THA036S2-1, THA048B2-1, THA048S2-1, THA060B2-1, THA060S2-1, THA090S2-1, THA090S2-2, THA090S2-3, THA102S2-1, THA102S2-2, THA102S2-3, THA120S2-1, THA120S2-2, THA120S2-3, THA150S2-1, THA150S2-2, THA150S2-3, TPA090S4S-1, TPA120S4S-1, TSA072S4-1, TSA090S4-1, TSA120S4S-1

    If you have any questions or would like to confirm part fitment, please call us at (734) 326-3900 and speak with one of our technicians.
