Lennox 80K12 Ignition Control Module

No reviews yet Write a Review
$291.02
SKU:
80K12
Condition:
New
Weight:
2.00 LBS
  • Technical Hot & Cold BBB Business Review

Lennox 80K12 Ignition Control Module

$291.02
  • Part Info & Specifications

  • Includes:

    • (1) - Ignition Control Module
    • (1) - Instructions (06-235580-003, Rev AC)

    Specifications:

    • Automatic Ignition System
    • Input: 24 VAC, 50/60 HZ, 300 MA
    • Valve: 24 VAC, 2A Max
    • Pre-Purge: 30
    • Interpurge: 30
    • Ignition Time: 7 sec
    • CAN/CSA C22.2
    • Control: 18 30 VAC 50/60hz
    • Class 2 Transformer
    • 300mA max@ 24 VAC with blower and gas valve relay energized (control only)
    • Output (Contact Rating)
    • 2.0A max @24 VAC
    • Combustion Blower (Model 35-61 only)
    • 3.0 FLA @120VAC (6.0 LRA)
    • 1.5 FLA @ 240 VAC (3.0 LRA)
    • 1/4 H.P. Motor
    • Operating Temp. -40ºF to +176ºF (-40ºC to +80ºC)
    • Flame Sensitivity: 0.7 A maximum
    • Flame Failure Response Time: 0.8 seconds maximum
    • Type of Gas; natural, LP or manufactured
    • Size: (LxWxH): 5.684" x 3.934" x 1.875" (with cover)
    • 5.281" x 3.718" x 2.080" (edge connect)

    Replaces Old Lennox Part Numbers:

    • 58C91
    • 15B51
    • 36G57
    • 80K1201
    • 58C9101
    • 36G5701
    • 15B5101

    Replaces Old Allied, Armstrong, Concord, Ducane Part Numbers:

    • R43806-001
    • 36G57
    • 80K1201
    • 36G5701

    Other Part Numbers:

    Fenwal Ignition Control, 131016, 6255110374, 1318DC, Cat-No. 35-605903-223, No.199-M89, 1318DC, Lennox P/N 80K1201, Direct Replacement for P/N 36G5701 and 98G2901, CAT. No. 35-605903-223, 1616DC, LOT (1T) 1616DC, 06-236489-001, JR , CH 24B-6, 94VO, 35-605903-223, NO.199-M89, Series 35-60, 35-61, 35.60/61A,

    Fits Models:(Press ctrl + F to find model number below if you have any questions call 734-326-3900 for further information)

    GCS11-953-175A-1, GCS11-953-175A-2, GCS11-953-250A-1, GCS11-953-250A-2, GCS16-090-200-1, GCS16-120-270-2, GCS16-1353-270-7, GCS16-1353-270-8, GCS16-150-270-1, GCS16-1603-270-3, GCS16-823-135-2, GCS16-953-200-7, GCS16W-413-75-4, GCS24-1603-270-1, GCS24-1853-235-1, GCS24-3003-470-1, GCS24-813-1, GCS24-813-2, GCS24-953-1, GCS24D-651-78-1, GCS24W-653-130-1, GCS4-311-90A-5, GCS4-311-90AN-5, GCS4-311-90AP-5, GCS4E-261-1, GCS4E-261-2, GCS4E-261-60A-1, GCS4E-261-60A-2, GCS4E-261-90A-1, GCS4E-311-60-1, GCS4E-311-90A-2, GHP16-1353-2, GHP16-1353-240-1, GHP16-953-1, GHP16-953-2, GHP24-650-1, GHP24D-653-95/130-1, LGB036H-1, LGB240H-2, LGB240H-4, LGE240H4-3, LGE240H4-4, LGE240H4-5

    Fits Allied, Armstrong, Concord, Ducane, Magic Chef, and Magic-Pak Models:(Press ctrl + F to find model number below if you have any questions call 734-326-3900 for further information)

    200GRTC89BL-4, 200GRTC89CL-4, 200GRTC89DL-4, 270GRTC119BH-4, 270GRTC119CH-4, 270GRTC119DH-4, GCS16-1353-270-3, GCS16-1353-270-5, GCS16-1353-270-6, GCS16-1353-270-7, GCS16-150-270-1, GCS16-1853-235-2, GCS16-2553-235-2, GCS16-2553-235-3, GCS16-2553-470-1, GCS16-2553-470-3, GCS16-2753-235-1, GCS16-2753-235-3, GCS16-2753-470-1, GCS16-2753-470-2, GCS16-2753-470-3, GCS16-953-200-6, GCS16-953-200-7

    If you have any questions or would like to confirm part fitment, please call us at (734) 326-3900 and speak with one of our technicians.
