York Coleman S1-02436204000 Blower Assembly

York Coleman S1-02436204000 Replacement Part

Includes:

• (1) - Blower Assembly (S1-02436204000)

Specifications

• Brand: Baldor Reliance Series: Super-E Motor Catalog Number: 11E1209 Spec Number: 36Q22ZR42862 Horsepower: 3.7 HP Voltage: 208-230/460 VAC Phase: 3 Phase Frequency: 60 Hz Full Load Amps: 9.88–9.4 / 4.7 A RPM: 1750 RPM Frame Size: 182T
• Shaft Diameter: 7/8"
• Shaft Length: 2-3/4" Service Factor: 1.15 NEMA Nominal Efficiency: 89.5% Power Factor: 81% NEMA Design: B Code: K Insulation Class: F Ambient Rating: 40C Continuous Duty Bearing – Drive End: 6206 Bearing – Opposite Drive End: 6205 Enclosure: OPSB (Open Drip Proof Style) Serial Number: F251190284

Note: Always check the blower wheel on your blower assembly. Bad or unbalanced blower wheels can cause premature motor failure due to vibration. If you are not sure what blower wheel fits your blower assembly, call us at 734-326-3900.

Replaces Old York Coleman Part Numbers

• There are no older part numbers.

Fits Models:

(Press ctrl + F to find model number below.)

Various. (Call 734-326-3900 with your model and serial number for more information.)
