York Coleman S1-32816419000 Condensate Drain Pan Assembly

No reviews yet Write a Review
11.00 LBS
  • Technical Hot & Cold BBB Business Review

York Coleman S1-32816419000 Condensate Drain Pan Assembly

  • Part Info & Specifications

  • Note: Furnace Models That Currently Use Blocked Condensate Pressure Switch (S1-02435776000) (-.40"w.c.) MUST Be Changed to Blocked Condensate Pressure Switch S1-02435812000 (-.20"w.c.)


    • (1) - Condensate Drain Pan (S1-32816419000)
    • (1) - Installation Manual (035-23922-002-G-0818)


    • MAX BTU: 80,000
    • Restrictor Diameter: 0.88"
    • Length: 17"
    • Width: 11 1/4"

    Country of Origin: USA

    Replaces Old York Coleman Part Numbers:

    • S1-32815544001
    • S1-02815544001
    • S1-32815544000
    • S1-02815544000
    • S1-02817579000
    • S1-02816419000
    • 541689

    Other Part Numbers:

    PAN CONDENSATE KIT 80M, York, Source 1, 5494059, 80000, S1-32816419000

    Fits Models:(Press ctrl + F to find model number below if you have any questions call 734-326-3900 for further information)

    CM9M080B12MP11, CM9M080C16MP11, CP9C080B12MP11, CP9C080B12MP12C, CP9C080B12MP13C, CP9C080C16MP11, CP9C080C16MP12C, CP9C080C16MP13C, GG9S080B12MP11, GG9S080C16MP11, GG9S080C22MP11, LM9M080B12MP11, LM9M080C16MP11, LP9C080B12MP11, LP9C080B12MP12C, LP9C080B12MP13C, LP9C080C16MP11, LP9C080C16MP12C, LP9C080C16MP13C, MG9S080B12MP11, MG9S080B12MP11, MG9S080C16MP11, MG9S080C16MP11, MM9E080B12MP11, MM9E080C16MP11, RGF19080BE12MP11, RGF19080BE12MP12, RGF19080BE12MP13, RGF19080BP12MP11, RGF19080CE16MP11, RGF19080CE16MP12, RGF19080CE16MP13, RGF19080CE20MP13, RGF19080CP16MP11, RGF29080BE12MP11, RGF29080BE12MP11, RGF29080CE16MP11, S1-02816419000, TG9S080B12MP11, TG9S080C16MP11, TG9S080C22MP11, TM9E080B12MP11, TM9E080B12MP12, TM9E080C16MP11, TM9E080C16MP12, TM9E080C20MP12, TM9M080B12MP11, TM9M080B12MP12, TM9M080C16MP11, TM9M080C16MP12, TM9T080B12MP11, TM9T080C16MP11, TM9V080B12MP11, TM9V080B12MP11C, TM9V080B12MP12C, TM9V080C16MP11, TM9V080C16MP11C, TM9V080C16MP12C, TM9X080B12MP11, TM9X080C16MP11, TM9Y080B12MP11, TM9Y080B12MP11, TM9Y080C16MP11, TP9C080B12MP11, TP9C080B12MP12C, TP9C080B12MP13C, TP9C080C16MP11, TP9C080C16MP12C, TP9C080C16MP13C, YM9M080B12MP11, YM9M080C16MP11, YP9C080B12MP11, YP9C080B12MP12C, YP9C080B12MP13C, YP9C080C16MP11, YP9C080C16MP12C, YP9C080C16MP13C

    If you have any questions or would like to confirm part fitment, please call us at (734) 326-3900 and speak with one of our technicians.
